The CyberMed R60 brings desktop-grade power to a compact, fanless chassis. Engineered for 24/7 reliability, it solves the challenge of providing secure, medical-grade computing in space-constrained areas like ORs and mobile workstations.
Near-Patient Electrical Safety
5-7 Year Product Consistency
Year-over-Year
Weighing Only 5.2lbs
Epic, Oracle Cerner & All Major EMRs
The fanless design prevents the circulation of dust and contaminants, maintaining a clean environment while ensuring silent operation in noise-sensitive patient areas.
Fully certified for near-patient use, this unit features the electrical isolation and EMI protection necessary for critical care and diagnostic integration.
Equipped with high performance Intel 15th Generation Series 2 Ultra processors to handle resource-intensive EMR software and medical imaging without performance throttling.
At just 5.2 lbs, the CyberMed R60 mounts easily via VESA or DIN rail, making it the perfect engine for medical mobile carts or slim wall mounts.
With both HDMI and DisplayPort outputs, the CyberMed R60 can power two independent 4K monitors simultaneously.
Features native RS232/422/485 ports to connect directly to legacy peripherals with zero latency.
The Standard in Modular Medical Compute
The CyberMed R60 is a professional-grade medical computer designed to operate where consumer PCs fail. By separating the processing unit from the display, IT teams gain the flexibility to build custom configurations. Whether paired with our medical grade monitors or integrated into a diagnostic equipment stack, the CyberMed R60 provides the longevity and stability required for modern healthcare environments.
Reduced Deployment Costs / ROI
Lower your total cost of ownership by standardizing on a fanless platform that eliminates the primary cause of hardware failure: dust-clogged fans and overheating. The CyberMed R60's energy-efficient design and 5-year lifecycle mean fewer replacements and reduced maintenance overhead. It is the ideal solution for non-powered medical mobile carts, allowing facilities to upgrade their digital infrastructure without the expense of replacing entire cart fleets.
Enterprise-Ready Implementation
Deployment is seamless thanks to a consistent BIOS and driver set that mirrors our all-in-one medical PCs. The CyberMed R60 is built for the enterprise, supporting secure boot and advanced networking requirements. For specialized projects, our OEM/ODM services can provide custom I/O configurations or internal hardware modifications to meet the specific throughput needs of your facility's software ecosystem.
Certified Patient Safety
Patient safety is at the core of the CyberMed R60's engineering. Beyond its antimicrobial exterior, the unit is fully compliant with global medical safety standards, ensuring it can be used safely in the "patient vicinity." This commitment to safety extends across our entire product line, from our rugged medical tablets to our embedded PCs, ensuring that clinicians can focus on care rather than hardware reliability.
| CPU Support |
15th Generation Intel® Core™ Ultra 5/7 Series 2 Processors |
| Chipset |
Intel H810 |
| Memory |
2x DDR5 SO-DIMM socket, populated up to 96GB |
| Operating System |
Windows 11, Windows IoT, Linux |
| Video & Graphics |
Intel® Graphics |
| Networking |
2x Gigabit GbE Intel (10/100/1000 Mbit) |
| Wireless |
WiFi 7 + Bluetooth 5.4 |
| Expansion Slots |
1x M.2 M Key 2242/2280/3052 PCIe x4 Support |
| Storage |
2x 2.5" Solid State Drives up to 2TB |
| Display Outputs |
HDMI / 7680 x 4320 @ 60Hz |
| TPM |
TPM 2.0 Support |
| Power Supply |
Unit supports 12V-28VDC Input |
| IP Rating |
IP65 Sealed Front Bezel and IPX1 Back Cover |
| Pressure |
700 to 1060hPa (0~3000 meters) |
| Dimensions |
7.96" x 7.67" x 2.28" (L,W,D) |
| Weight |
5.2 lbs |
| Wall Mount |
Custom Mounting Bracket for Wall, VESA, Din Rail or Rack Mount Solutions |
| Environment |
Operating Temperature: 0°C~35°C |
| Relative Humidity |
5%~95% (non-condensing) |
| Shock & Vibration |
IEC60068-2-27 & IEC60068-2-64 |
| Certifications |
IEC60601-1, IEC60601-1-2, EN60601-1, FCC class B, CE, Energy Star, RoHS, WEEE, REACH |
| I/O Ports |
1x USB4/Thunderbolt™4 (5V/3A, supports DP 2.1) |
| Audio |
1x Microphone Jack |
| Warranty |
3 Years* Standard with Optional Plans up to 5 Years |
|
Notes: |
Absolutely! Please reach out to one of our sales representatives for more information.
Yes. As part of our customization options, you can select legacy ports that work with your hospital's older devices such as serial ports, or parallel ports.
Opting for a medical-grade computer ensures enhanced patient and staff safety, regulatory compliance, and suitability for the unique demands of healthcare environments, making it the preferred choice for medical applications. You can learn more about medical-grade computers and why they're superior to regular computers in our in-depth analysis.
Yes. The processor and chipset are ready for Windows 11 and fully supported.
Yes. Cybernet publishes Microsoft Configuration Manager drivers on our support page. Should you have any questions, simply reach out to our support team for prompt support.
Complete your medical computing solution
"The Rugged Workhorse"
"AI Clinical Performance"
"Small Form Clinical"
Every Cybernet system is built to your exact requirements. We complete all configuration, imaging, and validation before shipment. Your team receives fully prepared units that can be deployed immediately, eliminating staging time, reducing IT workload, and avoiding costly delays.
Pre-configured drive images ready for your EMR system
Security and boot settings tuned to your IT policies
Barcoded and registered for your inventory system
Units arrive configured and ready for deployment
