Medical Cart Computers with
Three Hot Swap Batteries

Ideal for Non-Powered Medical Carts

  • Never Plug In Your Medical PC Again
    Three hot swap batteries with a total runtime of 16 hours is ideal for non-powered carts. Learn More >>
  • Power your Printer and Barcode Scanner from the Computer
    With our revolutionary power output design, you can power your peripherals directly from the medical computer. No need for an electrical outlet or a battery-powered cart. Learn More >>
  • IP65 Sealed Front & Back Bezels
    The front and back bezels of our medical cart computers are completely sealed making them easy to clean and disinfect.
  • EN60601-1 Certified / Antimicrobial Housing
    EN60601-1 certified to be safe for near patient use. Antimicrobial housing reduces the spread of germs. Ideal for OR and Emergency Rooms.
  • 6th Gen Intel Core CPU
    Our medical cart computers offer the Skylake 6th generation Intel Core i3/i5/i7 processor series. This CPU has up to 2.5x greater performance and 3x the battery life of most computers.
  • Lower Total Cost of Ownership (TCO)
    Powered medical carts are expensive to purchase and maintain. Our medical cart computers have a much lower TCO and reduce stress for your medical staff. Learn More >>
  • See Features
Free Lifetime Phone Support
U.S. Manufacturing & Technical Support
Fanless Medical Computer

Fanless for Sterile Environments

Our medical cart computers are fanless so they are ideal for sterile environments or where background noise is a consideration.

PCAP Multi Touch Screen

PCAP Multi Touch Screen

Our Medical Cart Computers have edge-to-edge tempered glass with anti-glare technology and comes standard with multi-touch technology.

VESA Mountable

VESA Mountable

Our medical computers with hot swap batteries are perfect for mounting on on carts, walls or almost anywhere with standard VESA mount options of 75mm & 100mm.

Internal RFID Security / SSO

Internal RFID Security / SSO

Ensure your records are secure with Internal RFID security Imprivata OneSign (SSO).

Powerful Medical Cart Computers

Benefits

Powerful Medical Cart Computers

Our medical cart computers are designed with Intel's® powerful Skylake 6th Generation Core™ i3/i5/i7 CPU and solid state technology, giving power users the performance needed to run demanding medical applications. Combined with the DDR4 RAM, which increases speed, reduces the amount of heat generated and doubles the power savings, these medical computers are ideal as a medical cart computer.

Customize your medical computer with Solid State Drives ranging from 120GB up to 1TB, and 8GB up to 32GB of DDR4 memory. At Cybernet, we can configure your medical computer with RAID level I, add more serial ports and even install your custom OS image to help reduce the deployment time and free up your IT resources.

Our CyberMed NB22 & CyberMed NB24 medical cart computers are the world's first Fanless All-in-One PCs with hot swap batteries to have the Skylake 6th Generation Intel Core CPU.

Antimicrobial / 60601-1 Certified

Our medical cart computers have an antimicrobial housing reducing the spread of microbes. This helps stop the spread of hospital-borne illnesses and is optimal in sterile environments. These all-in-one medical cart PCs are also medically certified to meet the requirements of EN60601-1 for electrical and radiation emissions to be safe for near patient use.

Stands up to Chemical Cleanings

Medical computers are subjected to chemical cleansers to disinfect them, often multiple times a day. Our computers are designed to stand up to chemical cleanings without damage to the medical PC. Here is the list of chemical cleansers approved for use on our medical grade computers.

Power your Peripherals Directly from the Medical Computer

Power your Peripherals Directly from the Medical Computer

Our medical cart computers are each designed to be a standalone, mobile all-in-one computer that can power itself AND directly power peripherals such as barcode printers, scanners, card readers and more. Both models offer up to 60 watts of total power through a convenient DC power output jack on the I/O coastline.

The CyberMed NB22 or CyberMed NB24 can provide a single 9V/12V/20V/24V DC power output with a maximum of 60 watts at a given time.

Enjoy the freedom of using the cart, computer, and peripherals without ever having to plug in.

These are the only medical computers currently available on the market that offer the unique feature of powering peripherals directly from the computer.

Note: Please check the peripheral power requirements before plugging it into the CyberMed NB22 or CyberMed NB24 to prevent damage or injury. A peripheral requiring over 60 watts of power should not be plugged into our medical cart computers. If you have questions about what devices can be plugged into these computers, please contact us.

Medical Cart Computer with 16 Hours of Uninterrupted Uptime

16 Hours of Uninterrupted Uptime

The three hot swap batteries last a total of 16 hours before needing to be recharged or swapped out. That's more than an entire medical shift. Even when used with power-consuming peripherals, the batteries will last a full medical shift.

Medical staff will no longer waste their time on frequent recharges of their powered carts. Just put fresh hot swap batteries in the medical computer and it is good to go for an entire shift. One and done!

CyberMed NB24 Battery Powered Medical Computer

Three Hot Swap Batteries

Our medical cart computers come with three hot swap batteries and an optional 3-Bay Battery Charging Station, which charges all three batteries simultaneously as fast as four hours. The batteries will also be charged if you plug in the computer to an electrical outlet.

Designed with smart battery capacity sensor technology, our medical cart computers notify the user with on-screen information about battery health and capacity and when to replace the batteries. These medical computers can operate on a single battery while charging the other two batteries. They can also operate without batteries when plugged directly into AC.

Wireless

Both the CyberMed NB22 and the CyberMed NB24 come with Intel Dual Band Wireless-AC 7265 802.11 AC and Bluetooth 4.0 for wireless computing.

Medical Cart Computer with Battery Charging Station

Stop Looking for an Electrical Outlet

Because these medical cart computers run on three hot swap batteries, you never need to look for an electrical outlet to run your PC or to power your cart. With the hot swap battery system, you can run our medical cart computers 24x7 without ever having to plug them in.

Multi-Battery Charging Station

Charge up to three batteries simultaneously in the charging station. It takes approximately four hours to charge all three batteries. Keep batteries charged and ready and you never have to worry about running out of power. Simply replace a depleted battery from the CyberMed NB22 or CyberMed NB24 with a charged one; put the depleted battery in the charger and you are "good to go" in less than a minute.

Medical PC Perfect for Non-powered Medical Carts

For Use on a Non-Powered Cart

No need to pay for an expensive powered cart. With the CyberMed NB22 and CyberMed NB24, you can use a non-powered cart and still get the power & performance of a desktop computer.

  • The three hot swap batteries last about 16 hours. Simply replace the three hot swap batteries when needed.
  • On screen pop-ups tell you when the batteries are getting low or you can check the indicator lights.
  • Use with the optional battery charging station and always have fully charged batteries ready and waiting.
  • Weighs less than a battery-powered cart so it is reduces wear and tear on your medical staff.
  • Industrial grade components ensures it can handle the beating that medical cart computers take 24x7.
Medical Cart Computer with Powered Peripherals

Save Money on Operating Costs

Powered carts are expensive. The initial cost is often 5x that of a non-powered cart. The cost of replacing the cart battery is very expensive, too. Factor in downtime due to servicing them and the TCO is extremely high.

Compared to the TCO of powered carts, the cost of operation and maintenance of our medical cart computers is much less. Just not having to purchase the powered cart alone is a significant savings.

The hot-swap batteries are durable and safe – they last and let your staff get their job done without distractions, while you no longer spend money on expensive powered carts and their replacement batteries.

CyberMed NB22 Battery Powered PC EMR Ready

Mobile EMR Ready

Our Medical Cart Computers are ready to mount on any medical cart. Easily move your medical cart and computer around your facility and to patient rooms to do charting and access critical data as needed. Compatible with many EMR solutions including Epic, Cerner, PointClickCare and others. Epic, in particular, recommends a 24" All in One Medical Computer for its software. The CyberMed NB24 is ideal for use with Epic and exceeds many of Epic's requirements.

MVA LED / Embedded Privacy Filter

Our Medical Cart Computers come with a Multiple Viewing Angle LED so medical staff can better view the screen from different angles rather than just from standing directly in front of the computer.

Cybernet offers has an optional embedded privacy filter which maintains the privacy of medical records while on a medical cart going throughout the hospital.

CyberMed NB22 Easy Access to SSD

Easy Access to SSD

Remove one screw to gain access to the hard drive / SSD.

Instead of taking the entire computer apart in order to replace a hard drive, IT can remove one screw and have instant access.

CyberMed NB22 USB Ports & Legacy Ports

USB Ports & Legacy Ports

The CyberMed NB22 and CyberMed NB24 come with an abundance of ports including 4 USB 3.0 ports, 2 USB 2.0 ports and an RS232/422/485 port (with an option to expand to 4 COM ports).

Free Lifetime Phone Support

Free Lifetime Phone Support

Cybernet offers complimentary U.S. telephone support for every product we sell, for as long as you own your product. Unlike other manufacturers, we don't charge you for telephone support after one year.

Extended Warranties

Extended Warranties

With an extended warranty, you can add an extra layer of protection to our already industry-leading warranty term. We offer extended warranties for this product: up to 5 years.

Deployment & Imaging

Deployment & Imaging

Send us the final drive image on a USB key or a DVD media and we'll deploy the image on every computer you purchase from Cybernet. This reduces the deployment time. Take them out of the box, plug them in and you are ready to go. We store the image on our secure servers for future purchases.

Cybernet offers the imaging service free of charge.

Get a free, no-obligation quote on Medical Cart Computer.

Customize your configuration for an accurate quote.

Personalized Sales & Technical Support

Personalized Sales & Technical Support

At Cybernet, we provide premium U.S.-based sales and technical support. We're always here to help you with customization and personalized support to ensure that you find the right medical computer solution that fits your budget and timeline.

All Cybernet products are backed by industry award-winning U.S. Tech Support and local RMA service in Irvine, California.

Cybernet operates globally with operations in the U.S., U.K., Taiwan, China.

Medical Cart Computer Specifications

Hot-swappable Batteries
- 3x Hot-swap battery, 86~90Watts each
- Charge time: 4 hours
- Total battery life: 16 hours
Battery Maintenance

See our Battery Maintenance Guide on how to prevent damage to the batteries when not in use for extended periods.

Display
- Internal Panel Resolution: 1920 x 1080
- External Display Port Resolution: 3840 x 2160 @ 60hz (UHD 4k)
Intel CPU
6th Generation Intel® Core™ i3/i5/i7 processors with vPro technology
Operating System

Windows 10, Windows 8.1, Windows 8, Windows 7, Linux

Chipset

Integrated

Memory

2 x DDR4 1866/2133MHz SO-DIMM sockets, populated up to 32GB Max

HDD Support
- 1 x 6Gbps Serial ATA III ports
- Up to 1TB SSD
Intel HD Graphics

Standard: Intel® HD Graphics 520

TPM Support
2.0 Standard (optional 1.2)
Networking
- Dual Gigabit Ethernet
- 1x Gigabit (Gbe) Intel 1219V Jacksonville
- 1x Gigabit (Gbe) Realtek RTL 8111G
Audio
- 1x Line-out
- 1x Microphone
- 2-channel 2Watt speaker facing back
I/O Ports
CyberMed NB22 Ports - 4 X USB 3.0 ports, 2 x USB 2.0
- 1 x RS232/422/485 serial port, option to expand to 4 COM ports
- HDMI - In (Display Mode with Audio Int. Speaker)
- HDMI - Out
- 1x 4Pin DIN power Jack
Ctrl+Alt+Delete Button

Keyboard free solution for windows authentication into corporate domain via Ctrl+Alt+Del.

Webcam

Optional: 3.0 Megapixel Webcam

Touch Screen

PCAP Multi-touch Technology for super responsive performance, works with medical gloves

Wireless

Intel® Dual Band Wireless-AC 7265 802.11 AC + Bluetooth 4.0

Wall Mount

Supports both 75mm & 100mm VESA mounting holes

Expansion Slots
- 1x mPCIe connector for PCIe module
- 1x M.2 connector for SATA interface SSD
- 1x M.2 connector for WiFI module
Dimensions
CyberMed NB22
- 21.75" x 14.5" x 1.92" (L, W, D)

CyberMed NB24
- 23.50" x 14.8" x 2.10" (L, W, D)
Weight
CyberMed NB22
- 15.35 lbs without batteries and without base stand
- 18.25 lbs with 3 batteries and without base stand

CyberMed NB24
- 17.75 lbs without batteries and without base stand
- 20.65 lbs with 3 batteries and without base stand
Swivel Base

Optional base stand for desktop enables left/right rotation up to 60°. Tilt from -5 to 60°.

Certifications

EN60601-1, UL60950 electrical safety, FCC class B, CE, Energy Star 6.1, RoHS 2

Multicharge Station & Battery Specifications

Battery Type
Lithium Ion, 8 cell
Battery Capacity
5700mAh
Battery Nominal Output Voltage
15.12Vdc
Multicharge Station Color
White with Antimicrobial Agent
Input Power
19V/135W
Battery Charge Time
4.5 hours from 0-100%
Simultaneous Battery Charging
Yes
Weight
1.15kg (2.5kg with 3 batteries)
Dimensions
93.3mm x 343.4mm x 196mm (L, W, D)
Environment
- Operating Temperature: 0°C ~ 45°C
- Storage Temperature: 0°C ~ 85°
Relative Humidity
- Operating: 10-85% (non-condensing)
- Storage: 10-85% (non-condensing)
LED Indicators
- Charging Battery: Amber
- Fully Charged Battery: Green
Certifications
FCC, CE

Linux Compatibility

ubuntu logo

12.1

fedora logo

17

openSUSE logo

12.2

Intel Graphics GMA

Built-In

checkmark green

Built-In

checkmark green

Built-In

checkmark green
Intel Chipset

Built-In

checkmark green

Built-In

checkmark green

Built-In

checkmark green
Realtek Audio

Built-In

checkmark green

Built-In

checkmark green

Built-In

checkmark green
Realtek Dual LAN

Built-In

checkmark green

Built-In

checkmark green

Built-In

checkmark green
Intel WiFi n6230

Built-In

checkmark green

Built-In

checkmark green

Built-In

checkmark green
Touchscreen checkmark green

Requires Command
See Below

checkmark green

Requires Command
See Below

checkmark green

Requires Command
See Below

NVIDIA GT530/630M checkmark green

Requires Command
See Below

checkmark green

Requires Command
See Below

checkmark green

Requires Command
See Below

Driver installation instructions for single-touch
Touchscreen Configuration

Note: You may need to change the device number (10) to 9, 11, or 12 depending on your configuration.


Invert Axis:

xinput set-prop 10 "Evdev Axis Inversion" 0, 1

Swap Axis:

xinput set-prop 10 "Evdev Axes Swap" 1
Driver installation instructions for NVIDIA GPU
Ubuntu 12.1
sudo apt-add-repository ppa:ubuntu-x-swat/x-updates
sudo apt-get update
sudo apt-get install nvidia-current
Fedora 17

1. Change to root user

su

2. Make sure that you are running latest kernel and have latest SELinux policy packages. If not then update kernel and reboot

yum update kernel* selinux-policy*

3. Add RPMFusion Repositories (Free and Non-Free) 32-bit and 64-bit

yum localinstall --nogpgcheck http://download1.rpmfusion.org/free/fedora/rpmfusionfree- release-stable.noarch.rpm
http://download1.rpmfusion.org/nonfree/fedora/ rpmfusion-nonfree-release-stable.noarch.rpm

## OR ##

yum localinstall --nogpgcheck http://download1.rpmfusion.org/free/fedora/rpmfusionfree- release-stable.noarch.rpm

yum localinstall --nogpgcheck http://download1.rpmfusion.org/nonfree/fedora/ rpmfusion-nonfree-release-stable.noarch.rpm

4. Install nVidia proprietary drivers for GeForce 6/7/8/9/200/300/400/500 series cards
Select akmod, kmod or kmod-PAE from following.

yum install akmod-nvidia xorg-x11-drv-nvidia-libs
openSUSE 12.2

Please visit the following link for instructions:
https://en.opensuse.org/SDB:NVIDIA_drivers
